Implement Description
AVAILABLE IN 4, 5, 6 & 7 FOOT WIDTHS
Implement Specifications
4' DISC HARROW
Hitch: CAT 1
Disc Blade Size: 16"
Number of Disc/Gang: 3
Disc Spacing: 7 1/2"
Main Frame: 2" x 2" x .180" Carbon Steel Tube
Disc Gang Tube: 2" x 2" x .180" Carbon Steel Tube
Disc Gang Axel: 1" Carbon Steel
Angle - Front Gang: 0°, 7° & 14° to the Front
Angle - Rear Gang: 0°, 7° & 14° to the Rear
Weight: 402 lbs.
5' DISC HARROW
Hitch: CAT 1
Disc Blade Size: 16"
Number of Disc/Gang: 4
Disc Spacing: 7 1/2"
Main Frame: 2" x 2" x .180" Carbon Steel Tube
Disc Gang Tube: 2" x 2" x .180" Carbon Steel Tube
Disc Gang Axel: 1" Carbon Steel
Angle - Front Gang: 0°, 7° & 14° to the Front
Angle - Rear Gang: 0°, 7°, & 14° to the Rear
Weight: 449 lbs.
6' DISC HARROW
Hitch: CAT 1, CAT 2
Disc Blade Size: 18"
Number of Disc/Gang: 5
Disc Spacing: 7 1/2"
Main Frame: 2.5" x 2.5" x 0.25" Carbon Steel Tube
Disc Gang Tube: 2" x 3" x 0.25" Carbon Steel Tube
Disc Gang Axel: 1" Carbon Steel
Angle - Front Gang: 0°, 7°, 14°, 21°
Angle - Rear Gang: 0°, 7°, 14°, 21°
Weight: 702 lbs.
7' DISC HARROW
Hitch: CAT 1, CAT 2
Disc Blade Size: 18"
Number of Disc/Gang: 6
Disc Spacing: 7 1/2"
Main Frame: 2.5" x 2.5" x 0.25" Carbon Steel Tube
Disc Gang Tube: 2" x 3" x 0.25" Carbon Steel Tube
Disc Gang Axel: 1" Carbon Steel
Angle - Front Gang: 0°, 7°, 14°, 21°
Angle - Rear Gang: 0°, 7°, 14°, 21°
Weight: 770 lbs.
